Two Face Mark Light BD04

• Voltage: DC10-30V,DC12/24V
• Current: 0.15A (DC12V)
• Light source : 12 SMD led
  • BD04

  • Hilmo

  • BD04

Two Face Mark light BD04

• Voltage:  DC10-30V,DC12/24V

• Current:  0.15A (DC12V)

• Light source : 12 SMD  led

• Color   : red white   combination

• Function: 3wire ,red,,white brightness

• Install: bolt fixing

• Material: AS ABS

• Life span: 10000 hours

• Size & weight:   117*112*58 (mm)  182g

• Warranty:  one year

• Water proof : IP67

• Certification  : DOT SAE

• This product widely used by Truck ,Trailer and other special vehicle

• SMD LEDs, super bright and long life span  Engineered lens optics plus a reflector over PCB making the lamp bright and shiny for compliance

• PC lens and housing ultrasonically welded together to ensure a permanent and weather proof seal
