Led offroad light bar DWL02-05

  • DWL02-05

  • Hilmo

  • DWL02-05

LED offroad Light Bar DWL02-05

• Operating Voltage: DC9-32V

• Current:10A/DC12V,5A/DC24V( 21.5")

•  Light source & power: 120W(12*10W) LED ,and 20W,40W,60W,80W,100W,180W, 240W,280W,300W optional

•  Length:20.3”,and 4.6”7.8”10.9”14.1”17.2”29.7” 39.1”42.2” 50” optional

• Beam: Combo, Flood (60 degree), spot (30 degee) optional

• Material: diecast aluminum housing ,PC lens ,aluminum alloy mounting bracket

• Illumination: 86LM per Watt

• Color Temperature: 6500K

• Life   time : 50000  hours  above

• Size & weight:  520(L)*93(T)*64(H)mm       1.5kg

• Water proof: IP67

•Temperature: -40℃ - +80℃

• Warranty  : one year

• Certification: CE  EMARK ROSH


• available in the auxiliary lamp for  truck, Offroad, 4x4  and so on

• new design make more brighter,more far

•  high-quality diecast aluminum housing; advance head sink design,make long life

• Waterproof, Dust-proof, Rust-proof, Anticorruption ,It can be used in rain or bad environment. EMC design to prevent effect vehicle operation,

•  Easy to wire up, install and adjust,play and plug


Packing weight: KG  Packing size:cm  Packing Qty:pcs



HILMO Security is one of the biggest manufactory of warning lightbar ,siren and speaker in China which was found in 1998. With 13 branch office all over China, reliable quality and excellent after-sales service make HILMO brand gain very good reputation in China!
